Waterproof Mid Range RFID Reader / Integrated RFID Reader For Parking System

Product Categories

SUNSHINE RFID Technology Co.,Limited

Contact Now

Name: Waterproof Mid Range RFID Reader Integrated RFID Reader For Parking System
Brand: SUNSHINE
Price: 1 USD

Brand Name : SUNSHINE

Model Number : F5009

Certification : CE.ROSH

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T, Western Union

Packaging Details : Carton

Working Voltage : DC +12V

Working Temperature : -25～+65℃

Tag Protocol : EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C

Working Frequency : 840～960 MHz

Output Power : Software adjustable, step interval 1.0dB, maximum +30dBm

Output Power Flatness : ±0.2dBm

Contact Now

Mid - Range UHF Weigand 26 9dbi Integrated RFID Reader For Parking System

Product Advantage

Employed IMPINJ R2000 RF Chips, up to -82dbm receiving sensitivity and the highest performance in this field makes this module more suitable for harsh application environment.
High stability and reliability, 60*24 hours high temperature of workstation, can work stably and continuous.
Remarkable performance, can achieve a reading distance over 11m for single tag reading.
Remarkable performance in intensive tags reading, can attain a tags identification rate of 400tags/s.
Provide the most comprehensive functions SDK and ports, easy to integrate RFID software.
Enhanced noise suppression function for reliable data capturing.
High precision return signal strength (RSSI).
Excellent performance of anti-interference and lightning-proof design.
ABS industrial plastic case, rugged and durable.
Waterproof and dustproof, production grade is IP64.

Product Electrical Parameters

NO.	Name	Parameters
1	Working Voltage	DC +12V
2	Working Temperature	-25～+65℃
3	Working Humidity	≤95%(+25℃)
4	Storage Temperature	-40～+80℃
5	Tag Protocol	EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
6	Working Frequency	840～960 MHz
7	Supporting Working Areas	China 1, China 2 US, Canada and other regions following U.S. FCC Europe and other regions following ETSI EN 302 208 with & without LBT regulations Japan Korea Malaysia Taiwan
8	Output Power	Software adjustable, step interval 1.0dB, maximum +30dBm
9	Output Power Flatness	±0.2dBm
10	Receiving Sensitivity	-82dBm
11	RF Port Standing Wave	≤1.5
12	Reading Distance	≥14m(relate to tags type, transmitted power and application environment)
13	Multi-tags Reading	≥400tags/s
14	Interface Communication Rate	115200bps
15	Working Temprature Detection	Support
16	Intensive Read/Write Mode DRM	Support
17	Antenna Connection Protection	Support
18	RSSI	Support
19	Antenna Type	9dbi circular polarization antenna
20	Communication Port	RS485,RS232(DB-9)RJ45(100M Ethernet port)
21	Buzzer	Yes
22	Enclosure	ABS industrial plastic case
23	Dimension	28287.5CM
24	IP Grade	IP64

Interface definition

Waterproof Mid Range RFID Reader / Integrated RFID Reader For Parking System
